Support AC and DC power activation，ax. 1.5x DC overmatching，Support three-phase function，Adopt LCD display, more convenient operation，Optional WIFI or GPRS for remote monitoring，Supports 6 pcs in parallel, and it can be extended to 30kW.
Save more installation, commissioning costs
Reduce the use of fossil fuels and be more environmentally friendly
Increase the penetration of renewable energy
Continuous and stable power supply
PV expansion will be more convenient in the future
| Model | 05KL1D | |||||
| PV string input | ||||||
| Max. input power (kW) | 7.5 | |||||
| No. of MPPT trackers | 1 | |||||
| No. of strings per MPPT trackers | 1 | |||||
| Starting voltage (V) | 100 | |||||
| Max. input voltage (V) | 450 | |||||
| MPPT voltage range (V) | 100~430 | |||||
| Max. input current per MPPT (A) | 32 | |||||
| Max. short-circuit current per MPPT (A) | 37 | |||||
| Battery | ||||||
| Rated voltage (V) | 48 | |||||
| Battery voltage range (V) | 40~56 | |||||
| Max. input/output current (A) | 100/100 | |||||
| Battery type | Lithium /Lead-acid | |||||
| Battery communication | CAN | |||||
| Grid input | ||||||
| Rated voltage (V) | 230 | |||||
| Input voltage range (V) | 176~270 | |||||
| Rated grid frequency (Hz) | 50/60 | |||||
| Max. charging current (A) | 21.7 | |||||
| THDi | <3% | |||||
| Grid type | L+N+PE | |||||
| Generator input | ||||||
| Max. input power (kW) | 5 | |||||
| Max. input current (A) | 21.7 | |||||
| Off-grid output | ||||||
| Rated output power (kW) | 5 | |||||
| Rated output voltage (Vac) | 230 | |||||
| Max. output current (A) | 26.1 | |||||
| Rated output frequency (Hz) | 50/60 | |||||
| Voltage waveform | Pure sine wave | |||||
| THDu | <2% | |||||
| Power factor | 1 (0.8 leading-0.8 lagging) | |||||
| Automatic switching time (ms) | <10 | |||||
| Overload capacity | 110%, 60S/ 120%, 30S/ 150%, 10S | |||||
| Parallel capability | 6 pcs in parallel | |||||
| Protection | ||||||
| Protection supported | PV input reverse protection，Antislanding protection，Insulation resistance test，AC overcurrent protection，AC short circuit protection，AC overvoltage protection，AC undervoltage protection，DC/AC surge protection | |||||
| General data | ||||||
| Max. inverter efficiency | 94% | |||||
| MPPT efficiency | 99% | |||||
| Operating temperature (℃) | -25~60 | |||||
| Relative humidity | 5%-95% | |||||
| Operating altitude (m) | <2,000>2,000 Derating) | |||||
| Protection class | IP65 | |||||
| Weights (kg) | 17 | |||||
| Dimensions W*D*H (mm) | 467*454*200 | |||||
| Cooling | Natural | |||||
| Noise emission (dB) | <35 | |||||
| Display | LCD | |||||
| Communication interface | RS485 / WIFI (GPRS) / CAN / DRM / Dry-contact | |||||
| Self-consumption at night (W) | <15 | |||||
| Contamination level | Ⅱ | |||||
| Topological | Non-isolated | |||||
